N6

6-port change-over ball valves PN16

Product features

DN15 and DN25
Medium: water 5 – 90 °C
Maximum differential pressure: 2 bar
Rotation angle: 90°
Brass CW617N
Threaded connections ISO 228-1
6-port ball valve for heating/cooling change-over systems

Types

Type DN [mm] G [inch] Kvs 1 [m³/h] Kvs 2 [m³/h]
N6PC15AA 15 G½″ 1,9 1,9
N6P25AA 25 G1″ 4,25 4,25

Questions or request a quote for N6?

Our experts can help you with technical questions, product selection and provide a quotation for your project.

How to read the product code

Request a quotation for N6

Tell us about your project so we can prepare an quotation.

Quotation details
Project description

Google reCaptcha: Invalid site key.

dynamx™ patent numbers

European patent:

No. 2307938
No. 3812870
No. 4177697


United States patent:

No. 9823666

Chinese patent:

No. ZL200880130728.9

Registered community design RCD:

No. 001167076-0001
No. 004030633-0001
No. 004030633-0002
