QP.W91

Pressure sensor air/water

Product features

Active pressure sensors
Analoge output: 0 – 10 Vdc or 4 – 20 mA (adjustable)
UV: AC/DC 24 Volt
Mounting: G½“
Measuring range adjustable
Optional with LCD display (NFC)

Types

Analogue output
Type Measuring range [bar] Max. overpressure [bar]
QP.W91.016 0 – 2,5
0 – 6,0
0 – 10,0
0 – 16,0		 50
QP.W91.016.LCD 0 – 2,5
0 – 6,0
0 – 10,0
0 – 16,0		 50
MODBUS
Type Measuring range [bar] Max. overpressure [bar]
QP.W91.016.A 0 – 16,0
0 – 25,0
0 – 40,0
0 – 60,0		 120
QP.W91.016.A.LCD 0 – 16,0
0 – 25,0
0 – 40,0
0 – 60,0		 120
BACnet



Type Measuring range [bar] Max. overpressure [bar]
QP.W91.016.B 0 – 16,0
0 – 25,0
0 – 40,0
0 – 60,0		 120
QP.W91.016.B.LCD 0 – 16,0
0 – 25,0
0 – 40,0
0 – 60,0		 120

Downloads

TypeDocumentFile typeSize
DatasheetQP.W91 - Drukopnemer lucht/water - NLPDF870.3 KBView
CatalogCatalog 2026View
